Important: This online guide is a product-image-verified overview for the matched RIGNOX product. It uses the product page, product reference images, and visible lighting-function details to guide product-side checks. Confirm hidden vehicle-side fasteners, trim clips, and wiring access points on your exact vehicle before removal.
Safety warning: Do NOT use dielectric grease or weather-sealing grease on connectors or sockets. Grease can cause connection problems and may affect warranty coverage.
Matched product
- Product: 2009-2018 Ram 1500/2500/3500 & 2019-2024 Ram 1500 Classic LED Triple Projector Headlights | L-Shaped Dual Color DRL
- Product type: headlights
- SKU: H-RAM09
- Fitment: Fits 2009-2018 Ram 1500 (DS), 2019-2024 Ram 1500 Classic (DS chassis only), and 2010-2018 Ram 2500 / 3500 Heavy Duty. Covers all three factory setups — Quad Halogen reflector, Dual Reflector, and Halogen Projector with LED DRL. One configuration covers every truck on the list. DRL: White / Amber Two Choice
- Does not fit: 2019 and newer Ram 1500 (DT), including TRX and all other DT-chassis trucks. The Classic is badged “Classic” on the tailgate — check the badge before ordering.
- Product page: View matching RIGNOX product details
Why Choose RIGNOX LED Headlights?
Upgrade your Ram truck with RIGNOX LED Triple Projector Headlights, designed to provide a modern lighting style, vehicle-specific fitment, and a cleaner upgrade experience.
Plug-and-Play Style Installation: RIGNOX headlights are designed with vehicle-specific connectors and mounting points to provide a straightforward installation experience.
Brighter LED Projector Design: Upgrade your factory headlights with a modern triple projector LED setup designed for a sharper and more aggressive front-end appearance.
Modern Style Upgrade: Transform the front-end appearance of your Ram truck with a premium LED lighting design that delivers a cleaner, more modern look compared with factory halogen headlights.
Product image checkpoints
- The product reference images show direct-fit, plug-and-play style connection details. Match the supplied connector to the vehicle connector and confirm the lock tab seats fully before reinstalling trim.
- Back-side or plug detail images are available for this item. Compare those photos with the removed original lamp before routing the harness.
- The visible product-function references indicate projector beam output, low beam, high beam, DRL, sequential turn signal, white/amber switchback behavior checks for this product. Confirm beam pattern and function behavior before final bumper or grille reassembly.
- If the kit includes a decoder, resistor, control module, or relay, secure it away from heat, moving parts, water paths, and sharp metal edges. Do not add universal electrical parts unless support confirms they are needed.
Product notes
- Use the product reference images on this page as the product-side visual check for connector layout, rear housing shape, and lighting functions.
- Your truck may have left the factory with any of three headlight setups — Quad Halogen reflector, Dual Reflector, or Halogen Projector with LED DRL. They use different bulbs and different connectors, so compare your removed lamp with the reference images before connecting.
- The 2019-2024 Ram 1500 Classic uses the same DS body, mounting points and connectors as the 2009-2018 Ram 1500 — installation is identical. The redesigned 2019+ Ram 1500 (DT) is a different truck and is not covered by this guide.
- Original vehicle trim, clip style, and fastener locations can vary by year, trim, and previous repairs. Remove panels slowly and verify each fastener before pulling.
- Road-lighting compliance and off-road/show-use notes are product specific. Review the matching RIGNOX product page for the exact language for this item.
Before you begin
- Confirm the exact truck: DS or Classic only. If the tailgate does not read “Classic” and the truck is a 2019 or newer 1500, stop — that is a DT and these will not fit.
- Confirm the exact product: Compare the RIGNOX headlights to the product reference images, including rear housing, plug layout, lens style, and included modules.
- Work powered down: Park on level ground, switch the vehicle off, and disconnect the negative battery terminal when handling wiring.
- Protect body panels: Use clean towels or masking tape near painted edges around the hood, grille, bumper edge, or fender liner area.
- Do not force clips: If a lamp or trim panel does not move, stop and look for another fastener or locating pin.
- No grease on connectors: Do not apply dielectric grease or weather-sealing grease to connectors or sockets.
Tools and supplies
- Trim removal tool or panel clip tool
- Metric socket and ratchet set; verify exact sizes on the vehicle before removal
- Phillips and flat screwdrivers
- Clean microfiber towels and masking tape
- Electrical tape and zip ties for securing included harnesses only
- A wall or flat vertical surface for beam-pattern checking
Remove the original headlights
-
Remove the Upper Plastic Cover: Remove the upper plastic cover by releasing the four plastic push rivets. Carefully lift the cover away to access the front bumper mounting hardware.
-
Remove the Four 10mm Bumper Top Bolts: Remove the four 10mm bolts located along the top edge of the front bumper. Two bolts are visible on this side, while the remaining two bolts are located on the opposite side of the vehicle. After removing the four top bolts, carefully remove the front bumper assembly to access the headlight mounting bolts.
-
Remove the Headlight Mounting Bolts: Remove the two 10mm bolts securing the headlight bracket to the core support structure.
-
Release the Headlight Retaining Clip: Access the rear side of the headlight assembly through the wheel well area, then push up the white retaining clip to unlock the headlight assembly.
-
Remove the Factory Headlight: Carefully remove the factory headlight assembly and disconnect the factory electrical connector.
Install the RIGNOX headlights
-
Connect the RIGNOX Headlight Main Power Plug: Connect the RIGNOX headlight main power plug to the factory electrical connector. Then connect the Daytime Running Light (DRL) butt plug to the other headlight’s DRL power wire and connect it to the battery positive terminal (+).
-
Test Lighting Functions Before Final Assembly: Before reinstalling and securing all removed components, test all lighting functions to ensure the RIGNOX headlights are working properly. Once everything is confirmed, reinstall and secure all parts.
Electrical and function test
- Confirm low beam and high beam operate on both sides.
- Confirm DRL, parking light, amber turn signal, hazard, sequential, and switchback behavior where supported by this product.
- Confirm startup animation or RGB/app functions only after normal road-light functions pass.
- Check for dashboard warnings, flicker, or intermittent operation before reinstalling final trim.
- Verify beam aim after installation so the cutoff is safe and even.
Final check
- All connectors are locked, dry, and routed without tension.
- Included modules or extra harnesses are secured away from heat, water paths, moving parts, and sharp edges.
- Both headlights sit flush with even body gaps and properly seated seals.
- All supported lighting functions pass on both sides.
- No warning lights, flicker, hyperflash, abnormal heat, moisture issue, or loose wiring remains after a short check drive.
Troubleshooting
- One lamp does not turn on: Recheck the main connector lock, related fuse, and battery connection.
- One function does not work: Compare the plug area to the product reference images and verify the connector is fully seated.
- Warning message, flicker, or hyperflash: Confirm the correct product variant was installed and that any included decoder, resistor, or relay is connected and secured.
- Moisture appears: Light condensation may clear as the lamp warms. Heavy or persistent moisture should be documented with photos before continued use.
- Beam pattern is too high or uneven: Recheck lamp seating first, then adjust aim on a flat surface.
Need help?
If the original lamp, vehicle connector, or included harness does not match the product reference images, stop before modifying wiring. Contact RIGNOX support with your order information, vehicle year/model/trim, product variant, and clear photos of the connector area, rear housing, beam output, and installed front-end gap.
End of installation guide. (c) RIGNOX - All Rights Reserved.
