Important: This online guide is a fitment-aware overview for the matched RIGNOX product. Before removing original parts or connecting wiring, review the installation reference images on this page and confirm the connector layout, transferred parts, wire routing, and vehicle-specific fastener locations for your exact vehicle.
Safety warning: Do NOT use dielectric grease or weather-sealing grease on connectors or sockets. Grease can cause connection problems and may affect warranty coverage.
Matched product
- Product: 2015-2023 Dodge Charger LED Quad Projector Headlights
- Product type: Headlights
- SKU: H-CHA15-CRGB, H-CHA15-CW
- Variants: Clear RGB w/ App Control; Clear White
- Fitment: Fits: 2015-2023 Dodge Charger with stock halogen projector or OE HID/Xenon projector headlights (includes vehicle-specific converter). Does not fit: 2015-2023 Charger originally equipped with OE LED projector headlights; models with prior wiring conversions unless specifically confirmed. DRL: White
- Product page: View matching RIGNOX product details
Product notes
- Sequential, startup, or animation functions are product/variant dependent. Test them before final reassembly.
- RGB/app-controlled functions apply only to RGB variants and should be used according to local road-lighting regulations.
- The matched product page references road-lighting compliance information. Review the product page for the exact compliance language for this item.
Installation reference images
Before you begin
- Vehicle/product: 2015-2023 Dodge Charger LED Quad Projector Headlights.
- SKU check: Confirm your kit SKU or variant matches H-CHA15-CRGB, H-CHA15-CW before removing original parts.
- Reference-first workflow: Review the installation reference images on this page before removing trim or connecting wiring. This guide includes confirmed details from the available reference text and images.
- Power and safety: Switch the vehicle off before unplugging connectors. Disconnect the negative battery terminal when handling wiring, fuse taps, or exposed circuits.
- Protect the vehicle: Use clean towels or masking tape around painted panels and trim edges. Do not force clips or pry against painted surfaces.
- No connector grease: Do not apply dielectric grease or weather-sealing grease to connectors or sockets.
- Headlight note: Keep bumper and liner hardware organized by position, and leave access open until the beam and DRL tests pass.
- Note: Fastener quantities and connector layouts may vary slightly depending on the vehicle's model year and trim. Check the actual vehicle configuration before removal, and never force the bumper, wiring harnesses, or connectors.
Reference image checkpoints
- Connector layout: Compare the vehicle connector count, pin count, and adapter harness shown in the reference images before plugging in the RIGNOX headlight.
- Trim level differences: If the reference images show low, mid, high, halogen, LED, or ACC differences, match the page that corresponds to your vehicle before powering the lamp.
- Harness routing: Route DRL, turn-signal, decoder, fuse-tap, or adapter harnesses exactly along the path shown. Keep wiring away from sharp bumper brackets, radiator support edges, and hot components.
- Beam adjustment: Identify the vertical and horizontal adjusters before the bumper is fully reinstalled so beam aim can be corrected after testing.
- RGB/app variants: Confirm controller power, pairing, mode change, and local road-lighting use before final trim reassembly.
Confirmed reference details
- Lighting functions: The reference identifies DRL, position light, sequential/flowing turn signal, low beam, and high beam testing points.
- RGB variants: When DRL is on, RGB lens lighting follows the light-guide color. When position lights are on, the RGB lens lighting is shown as off in the reference.
- Switchable features: The reference shows yellow/white light-guide switching for DRL/position light and startup animation/sequential turn switching.
- High-end adapter cable: The adapter is shown plugging between the headlight main plug and the vehicle wiring harness. Confirm this before powering the lights.
- Aiming: The reference marks up/down and left/right adjustment points. Perform beam adjustment before final road use.
Tools and supplies
- Trim removal tool or panel clip tool
- Metric socket and ratchet set; confirm the exact socket sizes against the reference images before removal
- Phillips and flat screwdrivers
- Clean microfiber towels and masking tape for painted bumper and fender edges
- Electrical tape and zip ties for securing included harnesses only
- A wall or flat vertical surface for beam-pattern checking after installation
- A helper for brake, turn, high-beam, and low-beam testing
Remove the original headlights
-
Remove the Upper Radiator Cover: Use a plastic trim removal tool to carefully release and remove all push clips securing the upper radiator cover. Store the clips in a safe place, then lift the cover upward and remove it to expose the upper bumper mounting points.
-
Remove the 10mm Fender-to-Bumper Bolts: Locate the 10mm bolts connecting the fender area to the front bumper on both sides of the engine bay. Remove each bolt with a 10mm socket, then repeat the same procedure on the opposite side.
-
Remove the Six 7mm Lower Screws: From underneath the front of the vehicle, locate the six 7mm screws securing the lower splash shield to the front bumper. Remove them one at a time with a 7mm socket while supporting the panel to prevent it from dropping when the final screw is removed.
-
Remove the Four Inner Wheel-Well Clips: Turn the front wheel to one side to create additional working space. Use a plastic trim tool to remove the four clips securing the inner fender liner, then repeat on the opposite side. Avoid excessively bending the liner, as this may cause permanent deformation.
-
Release the Fender Liner and Splash Guard: Remove the two additional plastic clips and three 7mm screws located inside the wheel-well area. Once all fasteners have been removed, gently pull the splash guard or fender liner outward to separate it from the bumper and expose the connectors behind it.
-
Disconnect the Side Marker Connector: After moving the fender liner aside, locate the side marker light connector behind the bumper. Press the locking tab and pull the connector apart by holding the plug housing. Do not pull directly on the wires, as this may damage the terminals or wiring harness.
-
Disconnect the Fog Light Connector: Locate the fog light connector behind the bumper, press its locking tab, and disconnect it. Depending on the vehicle configuration, connectors may be present on both sides. Confirm that all related wiring has been disconnected before removing the bumper.
-
Remove the Fender-to-Bumper Mounting Bolts: From inside the wheel well, remove the two bolts securing the front bumper to the fender. Repeat the procedure on the opposite side while supporting the side of the bumper to prevent it from releasing unexpectedly. Verify that all upper, lower, and side fasteners and electrical connectors have been removed. With one person supporting each side, gently release the bumper tabs beginning at the wheel-well edges. Pull the bumper assembly straight forward and place it on a clean, soft surface to protect the painted finish.
-
Remove the Factory Headlight Assemblies: Use an 8mm socket to remove the four bolts securing each factory headlight assembly. Support the headlight and carefully pull it forward to access the main connector at the rear. Press the connector's locking tab, disconnect the wiring harness, and remove the headlight. Repeat the procedure on the opposite side.
Install the RIGNOX headlights
-
Inspect and Configure the RIGNOX Headlight Connectors: Before installation, inspect the RIGNOX headlight housing, mounting brackets, and all connectors for damage. Configure the lighting functions according to the connector labels on the rear of the headlight: Connector A: Connect to enable the startup animation; disconnect to disable the animation. Connector B: Connect for a white daytime running light; disconnect for a yellow daytime running light. Connector C: The main power connector that connects to the vehicle's factory headlight harness. Confirm that the selected configuration matches the desired lighting effect. Secure any unused connectors away from hot, sharp, or moving components. Connect the vehicle's factory headlight harness to the main connector on the RIGNOX headlight. Push the connector together until the locking tab fully engages.
-
Test All Lighting Functions Before Final Assembly: Temporarily position the headlights and switch on the vehicle's electrical power. Test the low beams, high beams, daytime running lights, turn signals, and startup animation if enabled. Confirm that both sides operate consistently in brightness, color, and function. If any function does not work correctly, turn off the vehicle and recheck the main connector, function connectors, and locking tabs.
Electrical and beam test
- Test low beams, high beams, DRL, parking/position lights, left and right turn signals, hazards, side markers if equipped, and startup animation if equipped.
- Confirm there is no flicker, warning message, hyperflash, or inactive side.
- If a fuse-tap or ACC harness is shown, confirm it is seated in the correct fuse position and secured before closing the fuse box.
- Check beam aim against a flat wall and adjust vertical/horizontal aimers as needed before final bumper reassembly.
- For RGB/app variants, confirm controller power, app pairing, normal mode, RGB mode, speed/brightness controls, and the mode required for road use.
- After all tests pass, reinstall bumper covers, liners, clips, and trim panels.
Final check
- All connectors are fully seated and locked.
- All included harnesses are secured away from movement, sharp edges, water paths, and heat sources.
- Headlight beams are aimed correctly and both sides sit with even bumper and fender gaps.
- All headlights functions test correctly on both sides with a helper operating the controls.
- No warning lights, hyperflash, flickering, abnormal heat, moisture entry, or loose modules remain after a short function check.
Troubleshooting
- One headlight does not turn on: Recheck the main connector, adapter harness, fuse tap if used, and ground connection shown in the reference images.
- DRL or turn signal does not work: Confirm the DRL/turn harness or ACC connection matches the vehicle trim shown in the reference images.
- Warning, flicker, or hyperflash appears: Recheck any decoder, resistor, or trim-specific adapter before adding universal parts.
- Beam pattern is too high, low, or uneven: Re-seat the lamp, confirm all retainers are tight, then adjust vertical and horizontal aimers.
- RGB/app feature does not respond: Confirm the product variant supports RGB, the controller has power, and the app or remote is paired before closing trim.
Need help?
If the connector, transferred part, or trim layout does not match the reference images, stop before modifying the vehicle. Contact RIGNOX support with your order information, vehicle year/model/trim, product variant, and clear photos of the headlight, connector, and harness layout.
End of installation guide. (c) RIGNOX - All Rights Reserved.
